Fiber Optic Gyroscope FOG for Reliable Motion Sensing and Navigation in UAV

Name: Fiber Optic Gyroscope FOG for Reliable Motion Sensing and Navigation in UAV
Brand: Shenzhen Fire Power Control Technology Co., LTD
SKU: MFOG-24
Price: 695.00 USD
Availability: InStock

Nama merek:	Firepower
Nomor Model:	MFOG-24
Moq:	1
harga:	650~740USD
Ketentuan Pembayaran:	L/C,T/T
Kemampuan Penyediaan:	500/bulan

Informasi Rinci

Deskripsi produk

Informasi Rinci

Tempat asal:

Cina

Berat:

30 gram

Pengulangan Bias:

1,5/jam

stabilitas bias nol:

<1,5 derajat/jam

Jalan acak sudut:

0,003°/√ jam

Rentang Pengukuran:

500°/dtk

Dimensi:

φ24x39mm

Kemasan rincian:

spons/kotak

Menyediakan kemampuan:

500/bulan

Menyoroti:

Fiber optic gyroscope for UAV navigation

FOG motion sensor for drones

IMU gyroscope with reliable sensing

Deskripsi produk

Fiber Optic Gyroscope FOG for Reliable Motion Sensing and Navigation in UAV

Designed for demanding environments, the MFOG-24 is rugged, lightweight, and highly resistant to shock and vibration. With no moving parts, it delivers reliable performance and long service life.

Applications: Ideal for autonomous vehicles, robotics, and precision navigation systems.

Main Performance Parameters

Serial Number	Project	MFOG-24	MFOG-24-AN
1	Range (°/s)	±500	±300
2	Scale Factor	3600 (LSB/o/s)	7mv/o/s
3	Scale Factor Nonlinearity (ppm)	300	≤1000
4	Zero-Bias Stability (10s, 1σ, °/h)	≤1.5	≤2
5	Zero-Bias Repeatability (1σ, °/h)	≤1.5	≤2
6	Angular Random Walk (°/h 1/2)	≤0.03	≤0.04
7	Zero Bias (°/s)	≤0.02	≤0.05
8	3dB Band Width (Hz)	≥300	≥450
9	Power Supply (V)	5+0.15	5+0.15
10	Power Consumption (W)	≤1.5	≤0.7
11	Dimension (mm)	φ24X39
