Single Axis Fiber Optic Gyroscope Fog Fizoptika VG910F for Multi-Application Navigation

Single Axis Fiber Optic Gyroscope Fog Fizoptika VG910F for Multi-Application Navigation

Nama merek:	Firepower
Nomor Model:	MFOG-910
Moq:	1
harga:	1000$
Ketentuan Pembayaran:	L/C, D/P, T/T, Western Union
Kemampuan Penyediaan:	500/bulan

Informasi Rinci

Deskripsi produk

Informasi Rinci

Tempat asal:

Jangkauan:

±240°/dtk

Stabilitas Zero-Bias ((10s, 1σ):

≤0,8°/jam

Jalan acak sudut:

≤0,02°/jam

Bandwidth 3DB:

≥1000Hz

Pengulangan nol bias ((1σ):

≤0,8°/jam

Nonlinier faktor skala:

≤ 1000 ppm

Berat:

≤150g

Konsumsi daya:

≤1.5w

Kemasan rincian:

Spons + karton

Menyediakan kemampuan:

500/bulan

Menyoroti:

single axis fiber optic gyroscope

fiber optic gyro for navigation

Fizoptika VG910F gyroscope

Deskripsi produk

Single Axis Fiber Optic Gyroscope FOG Fizoptika VG910F

Multi-Application Navigation Solution

Key Specifications

Attribute	Value
Range	±240°/s
Zero-bias stability (10s, 1σ)	≤0.8°/h
Angular random walk	≤0.02°/h
3dB Bandwidth	≥1000Hz
Zero-bias repeatability (1σ)	≤0.8°/h
Scale factor nonlinearity	≤1000ppm
Weight	≤150g
Power Consumption	≤1.5W

Product Overview

The MFOG-910 Micro-Nano Fiber Optic Gyroscope is a high-performance angular rate sensor integrating optical, mechanical, and electronic systems into a compact, robust unit. Utilizing the Sagnac effect with counter-propagating light beams in a micro-nano optical fiber coil, it delivers precise angular velocity detection.

Key Features

All-solid-state design with no moving parts for maximum reliability
Fast startup and long operational life (≥15 years)
Exceptional resistance to shock (≥1500g) and vibration (≥70g)
Compact size (≤150g) with low power consumption (≤1.5W)
High MTBF (≥100,000 hours calculated assessment)
Temperature-compensated for stable performance

Performance Parameters

Parameter	Specification
Scale factor (mV/°/s)	47±5
Power supply (V)	5+0.25+12
Impact resistance	≥1500g
Acceleration resistance	≥70g

Product Diagrams

Front View Outline Diagram

Side View Outline Diagram
